Architectural · A-WNY58

Acoustic Panel Detail

Scale: SCALE: 3" = 1'-0"
Units: imperial
Sheet: A5
Discipline: Architectural

Materials

Aluminum Metal (misc.)

Elements

Facades / Cladding Walls

Text on the drawing

UTILITY BLDG MAIN LEVEL 99'-0" Level 1 101' - 0"

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
