A loading dock pit is formed within a tilt-up concrete wall, edged with a structural dock angle sized per the manufacturer. Electrical routing features a three-quarter-inch conduit with a six-inch stub out connecting a branch tee to the dockleveler control box, which then routes to the electrical breaker per the manufacturer. Dimensions for the pit and wall integration are determined per the manufacturer specifications.
SEE MANUF. SEE MANUF. SEE MANUF. SEE MANUF. SEE MANUF. SEE MANUF. SEE MANUF. 3/4" CONDUIT, 6" STUB OUT TO BREAKER, SEE ELECTRICAL DOCKLEVELER CONTROL BOX BRANCH TEE DOCK ANGLE. CL PIT TILT-UP WALL
