A pipe penetrates through a roof assembly consisting of a concrete deck, vapor barrier, rigid insulation, cover board, and roof membrane. A pre-fabricated insulated curb with a metal face and base leg and a non-combustible nailer surrounds the penetration, extending eight inches minimum above the roof surface. Roof membrane flashing runs up and over the curb with a six-inch minimum lap. A pre-manufactured metal cap flashing and sealant are installed by the mechanical contractor over the curb, paired with a storm collar and membrane manufacturer standard flashing membrane around the pipe.
MEMBRANE MFR STANDARD FLASHING MEMBRANE STORM COLLAR BY MECHANICAL CONTRACTOR PRE-MANUFACTURED METAL CAP FLASHING & SEALANT BY MECHANICAL CONTRACTOR ROOF MEMBRANE FLASHING RUN UP AND OVER CURB ROOF MEMBRANE COVER BOARD RIGID INSULATION VAPOR BARRIER \ RETARDER 6" MIN. PRE-FAB. INSULATED CURB WITH MTL. FACE & BASE LEG & NON-COMBUSTIBLE NAILER 8" MIN. 8 7
