A downspout receives discharge from the Rae Bridge above with a six-inch clear gap leading into a downspout funnel installed per manufacturer requirements. The downspout is attached to the tower guard using galvanized strut channels. The assembly extends downward to connect to the tower column.
TOWER 04 DOWNSPOUT FROM RAE BRIDGE DOWNSPOUT FUNNEL PER IMP MFR DOWNSPOUT PER IMP MFR, ATTACH TO GUARD W/ GALV STRUT CHANNEL DOWNSPOUT TO TOWER COLUMN TOWER GUARD PER PLAN GAP 6" 4'-2"
