A-WFH5X — Ribbed Metal Panel Wall Assembly with Flanged Frame

Architectural · A-WFH5X

Ribbed Metal Panel Wall Assembly with Flanged Frame

Materials

Timber / Wood Metal (misc.)Gypsum / Drywall

Elements

Facades / Cladding Waterproofing / Flashing

About this detail

An eight-inch galvanized sheet metal flange runs all around the frame to provide a seal against moisture intrusion. The ribbed metal panel is installed over a weather resistive barrier, five-eighths-inch exterior gypsum board, and six-inch metal studs.

8" GSM FLANGE ALL AROUND FRAME PROVIDING SEAL RIBBED METAL PANEL ON WEATHER RESISTIVE BARRIER OVER 5/8" EXT. GYP. BD. OVER 6" METAL CH STUD
