This parapet wall assembly consists of a light-gauge steel stud frame capped with a wood blocking member. A metal coping flashing is mechanically fastened to the exterior face of the wall, providing a weather-tight seal over the top of the panel system. The assembly incorporates specific material specifications referenced by codes 07 5423.N, 07 4213.19.A, 06 1053.A, 05 4000.A, and 06 1600.F. The panel thickness is indicated as a variable dimension to be verified against the structural requirements.
