A C10x15.3 channel member connects to a precast concrete wall panel using a 6-inch embedment anchor. The channel sizing for the framing is determined per plan, with a line of wall shown beyond. A vertical post support beneath the channel bears down to a concrete footing foundation. The assembly coordinates the structural interface between interior mezzanine framing and exterior precast wall panels.
