A Balco FCWW-4 seismic expansion joint is positioned between a solid-grouted concrete masonry unit wall and an exterior insulation and finish system assembly. The joint is finished to match the exterior finish coat. Framing includes structural steel shapes and metal studs configured at the building intersection.
W1 H BALCO FCWW-4 SEISMIC EXPANSION JOINT, FINISHED TO MATCH E1 EIFS FINISH COAT CONCRETE MASONRY UNIT GROUTED SOLID 1' - 0 3/8" 1' - 3 1/8" 2" 4" ELECTRICAL 261
