An aluminum relite frame integrates with a framed wall construction featuring double studs or a structural jamb stud as specified in structural plans. The aluminum frame anchors directly to the jamb framing studs. A continuous sealant bead is applied at the interface on each side to seal the joint.
WALL TYPE PER PLANS PROVIDE DOUBLE STUD OR JAMB STUD PER STRUCT RELITE TYPE PER PLANS SEALANT BEAD EACH SIDE
