A prefinished sheet metal coping caps the parapet wall, extending over foil-faced self-adhered flashing applied to the top plate. SBS membrane roofing terminates at the curb with counterflashing. Insulated metal wall panels attach to exterior metal framing backed by a weather barrier and interior gypsum board.
07 62 00 - PREFINISHED SHEET METAL FLASHING AND TRIM 07 25 00 - WEATHER BARRIER 8" MIN SEE ASSEMBLIES 07 62 00 - COUNTERFLASHING 07 25 00 - FOIL FACED SELF-ADHERED FLASHING 07 52 00 - SBS MEMBRANE ROOFING 07 42 14 - INSULATED METAL WALL PANELS 09 21 16 - 5/8" TYPE X GYPSUM BOARD 09 21 16 - METAL FRAMING, SIZE PER PLANS
