A-WCVY5 — 1/4" Aluminum Divider Strip at Epoxy Terrazzo

Architectural · A-WCVY5

1/4" Aluminum Divider Strip at Epoxy Terrazzo

Materials

About this detail

A one-quarter-inch aluminum divider strip is embedded within an epoxy terrazzo topping. The epoxy terrazzo sits over a bonding agent applied directly to the concrete substrate. The adjacent finished flooring surfaces align flush with the top of the divider strip.

ALIGN ALIGN EPOXY TERRAZZO BONDING AGENT 1/4" ALUMINUM DIVIDER STRIP ALIGN ALIGN EPOXY TERRAZZO BONDING AGENT 1/4" ALUMINUM DIVIDER STRIP
