An aluminum storefront frame and door head assembly is mounted below a metal framing header of a wall assembly per plan. A continuous backer rod and sealant are installed on both sides of the frame junction. The adjacent spaces are identified as a classroom and a public hallway.
ALUMINUM STOREFRONT FRAME AND DOOR, REF SCHEDULE CONTINUOUS BACKER ROD + SEALANT, BOTH SIDES OF FRAME PUBLIC/ HALLWAY MTL FRAMING HEADER WALL ASSEMBLY PER PLAN CLASSROOM 3/4" 3" 4" 6"
