An aluminum curtain wall outer corner wraps an HSS column specified per structural drawings. The structural column is framed by six-inch metal studs and wrapped with a continuous foil-faced self-adhering membrane beneath a fluid-applied air barrier. Formed aluminum closures and custom aluminum closure elements supplied by the curtain wall manufacturer finish the exterior transition. Glazed aluminum curtain wall mullions tie into the assembly with joints sealed using one-half-inch sealant and backer rod.
084413 ALUMINUM CLOUSURE BY CURTAIN WALL MANUF 6" MTL STUDS. SSD 084413 GLAZED ALUMINUM CURTAIN WALL MULLION 055000 FORMED ALUMINUM CLOSURE 079200 1/2" SEALANT AND BACKER ROD 072726 CONT. FOIL FACE, SAF BENEATH FLUID-APPLIED AIR BARRIER HSS, SEE STRUCTURAL DRAWINGS
