A-WBMPS — Canopy Axonometric

Architectural · A-WBMPS

Canopy Axonometric

Units: imperial
Sheet: A7.41
Discipline: Architectural

Materials

Metal (misc.)Steel

Elements

Anchors / Embeds Canopies Connections / Plates Decks

Connections

Deck Attachment Welded Connection

Text on the drawing

1 1/2" METAL DECK L 4X3 STEEL ANGLE DECK SUPPORTS WELDED TO FRAME C 6X2 CANOPY FRAME WELDED AND MITERED AT CORNERS PLATE STEEL TAB 3 CANOPY AXONOMETRIC NOT TO SCALE
