A canopy frame constructed from a six-by-two-by-one-eighth-inch channel connects via bolts through a tab. A one-and-a-half-inch metal deck holds back one inch from the perimeter above a metal head flashing and formed metal closer. Formed vertical and horizontal sub-framing supports the rainscreen assembly. A weather-resistive barrier laps over the jamb flashing to maintain the building envelope.
FORMED METAL CLOSER RIVET PER MFR FORMED VERTICAL FURRING FORMED HORIZONTAL SUB FRAMING METAL HEAD FLASHING WRB. LAP OVER JAMB FLASHING C 6X2X1/8 CANOPY FRAME 1 1/2" METAL DECK HOLD BACK 1" FROM PERIMETER BOLT (BEYOND) TO TAB THROUGH CHANNEL. 1" 1" SAM JAMB FLASHING
