An intermediate stair landing features a concrete fill with wire mesh reinforcement supported on a metal pan. A steel channel header frames the landing edge, reinforced with a steel angle stiffener below. A bent closure plate sits beyond the landing edge. Each pan includes two equally spaced three-eighth-inch holes at the back, and a three-inch sanitary cove finishes the transition.
3" SEE FLOOR PLAN SEE FLOOR PLAN BENT CLOSURE PLATE BEYOND CONC FILL WITH WIRE MESH REINF ON MTL PAN (TYP) STEEL ANGLE STIFFENER STEEL CHANNEL HEADER 3" SANITARY COVE PROVIDE 2 EQUALLY SPACED 3/8" HOLES AT BACK OF EACH PAN
