An exterior aluminum storefront system meets a framed exterior wall assembly that features a one-eighth-inch weathered Cor-ten steel panel over rigid insulation. A separate one-quarter-inch weathered Cor-ten steel screen panel is mounted on supplementary steel framing at an angle of twenty-one degrees relative to the main wall plane. The interior wall construction incorporates standard framing and insulation materials behind the storefront head and jamb framing.
EXTERIOR INTERIOR 21.00° ALUMINUM STOREFRONT SYSTEM 1/4'' WEATHERED CORTEN STEEL PANEL OVER STEEL FRAMING 1/8'' WEATHERED CORTEN STEEL PANEL OVER RIGID INSULATION AND FRAMED WALL AG12.4a 15
