A concrete-filled stair stringer assembly at an intermediate landing features standard tread dimensions with an 11-inch run and 1-inch typical overhang. The landing support is coordinated by the stair manufacturer, while slab thickness and structural support requirements are verified per structural drawings.
11" TYP. 1" . SEE STRUC. DWGS FOR SLAB THICKNESS CONC. FILLED INTERMEDIATE LANDING LANDING SUPPORT BY STAIR MANUF. STAIR STRINGER
