A reinforced roof membrane transitions up the concrete tilt-up wall panel and is secured with bonding adhesive, fasteners, and fastening plates installed per the manufacturer. Rigid insulation and steel roof deck or sheathing bear over a metal roof joist coordinated with structural drawings. A cut edge sealant is applied to the reinforced membrane at the termination. A note specifies to crease the membrane at the angle change to limit bridging to three-quarters of an inch maximum.
METAL ROOF JOIST, SEE STRUCTURAL TILT PANEL - SEE STRUCTURAL STEEL ROOF DECK OR SHEATHING - SEE STRUCTURAL NOTE: CREASE MEMBRANE AT ANGLE CHANGE TO LIMIT BRIDGING TO 3/4" MAX. BONDING ADHESIVE REINFORCED MEMBRANE FASTENER AND FASTENING PLATE INSTALL PER MANUF. INSTALL PER MANUFACTURER CUT EDGE SEALANT REINFORCED MEMBRANE, SEE PLAN RIGID INSULATION
