Concrete tilt-up wall panels feature a one-half-inch joint space. A backer rod is installed at each face with continuous sealant running from the footing to the top of the panel and across the joint. The panel edges feature three-quarter-inch typical chamfers.
CONC. TILT- UP WALL PANEL BACKER ROD AT EACH FACE WITH CONTINUOUS SEALANT FROM FOOTING TO TOP OF PANEL AND ACROSS 1/2" PANEL JOINT TYPICAL 1/2" 3/4" CHAMFER TYPICAL
