A wall-mounted swing-out equipment rack includes front and side elevations detailing structural attachment locations and junction box coordination. The backpan features six typical attachment points tying into the wall structure, with a twelve by twelve inch junction box cutout positioned behind the rack. Overall dimensions and vertical spacings are provided for the backpan, door assembly, and side profile.
VIEW A: FRONT VIEW BACKPAN ONLY VIEW B: FRONT VIEW WITH DOOR VIEW D: SIDE VIEW 2 ATTACHMENT TO STRUCTURE (TYP OF 6) SEE DETAIL G & H: ATTACHMENT DETAIL 12X12 J-BOX BEHIND RACK J-BOX CUTOUT 1' - 4" B A 1' - 11 7/8" 1' - 11 7/8" 1' - 11 7/8" 0' - 11 1/2"
