One-inch acoustic panels are adhered directly to a five-eighths inch gypsum board wall assembly. The gypsum board substrate is prepared to receive a low volatile organic compound adhesive. Mounting heights are coordinated with interior elevations and finish schedules.
WALL PER PLAN 5/8" GYP. BOARD. 1" ACOUSTIC PANEL. PREP WALL TO RECEIVE LOW V.O.C. ADHESIVE. SEE (AP-1) ON FINISH SCHEDULE FOR MOUNTING HEIGHT SEE INTERIOR ELEVATION FOR MOUNTING HEIGHT SEE INTERIOR ELEVATION 0'-1"
