Dimensional Layout of Glass Panels 26 and 27

About this detail

Glass panel twenty-six is a four-sided polygon defined by side lengths of two and one-half inches, four and fifteen-sixteenths inches, one and seven-eighths inches, and six and one-half inches, with interior angles measuring sixty-five point five degrees, one hundred nine degrees, one hundred thirteen degrees, and seventy-two point five degrees. Glass panel twenty-seven is a triangular shape defined by side lengths of six and one-half inches, six and eleven-sixteenths inches, and four and three-quarters inches, with interior angles measuring seventy-one degrees, sixty-seven degrees, and forty-two degrees.
