Steel Column Cap Plate Connection at Roof Level

Materials

Steel

Elements

Columns Roofs

Connections

Welded Connection

About this detail

A steel column extends upward to a roof elevation of 152 feet and 5 inches, centered beneath a cap plate measuring 3/8 inch by 6-3/4 inches by 8-3/4 inches. Framing members per plan connect at the column head with specific welding and seismic force-resisting system requirements, including a 1/4-inch fillet weld from the column to the cap plate while avoiding the K-area. A bottom flange plate with a minimum thickness of 1/2 inch ties the assembly together. Additional information for unshown conditions is referenced on sheet 3.S-327.
