Linoleum flooring meets carpeting over a concrete subfloor with a Schluter Reno-U transition profile maintaining a one-to-two maximum slope. Carpeting and linoleum thicknesses are coordinated per the finish schedule. Flooring transitions are restricted to a maximum height of one-half inch typically.
SLAB TOP OF SCHLUTER RENO-U FLOORING TRANSITION 1:2 MAX SLOPE LINOLUEM FLOORING- SEE FINISH SCHEDULE CONCRETE SUB - FLOOR, SEE STRUCTURAL DRAWINGS CARPETING - SEE FINISH SCHEDULE FLOORING TRANSITIONS TO BE NO GREATER THAN 1/2" , TYP.
