An orthogonal corner assembly for an aluminum and glass storefront system uses pre-finished aluminum extrusions backed by structural steel reinforcing as required. The outer glazing lines meet at a ninety-degree external corner with matching pre-finished aluminum trim profiles.
08 4400 ALUMINUM AND GLASS STOREFRONT SYSTEM, E-WA-01A 08 4400 PRE-FINISHED ALUMINUM, E-MTL-01 STRUCTURAL STEEL REINFORCING AS REQUIRED 08 4400 PRE-FINISHED ALUMINUM, E-MTL-06 STRUCTURAL STEEL REINFORCING AS REQUIRED
