A-VT6EX — Modular Rainscreen System - Horizontal Joint - Section

Architectural · A-VT6EX

Modular Rainscreen System - Horizontal Joint - Section

Scale: 3" = 1'-0"
Units: imperial
Sheet: A7.21
Discipline: Architectural

Materials

Aluminum Membrane / Roofing Stainless Steel Steel

Elements

Anchors / Embeds Facades / Cladding Insulation Waterproofing / Flashing

Connections

Bolted Connection

Text on the drawing

Z-FURRING @ 24" O.C. MODULAR RAINSCREEN PANEL EXTRUDED ALUMINUM CHANNEL WRB. 2" RIGID INSULATION 1/4" 1" 1" EXPOSED STAINLESS STEEL SCREW W/COLORED HEAD TO MATCH SIDING EW5
