This plan detail shows a single egress door jamb frame installed in a two-hour fire-rated partition wall. The assembly comprises metal stud framing clad with gypsum board layers on both faces, terminating at a hollow metal door frame profile. A header as scheduled spans above the opening, coordinated with the surrounding partition framing. Adjacent ceiling suspension systems tie into the wall assembly via standard track and wire hangers.
