Exterior wall transition between a vertical rib metal siding profile and an exterior Longboard 6-inch V-groove panel system. A continuous horizontal 2 1/2-inch 16-gauge zee profile provides backing and alignment to the window jamb where required. A hard-fastened J-track component secures the edge of the panel assembly using pan-head screws. Furring hat channels spaced at 32 inches on center support the exterior Longboard panels over the underlying weather barrier and insulation layers.
PLAN EXT. LONGBOARD 6" V- GROOVE PANEL PAN-HEAD SCREW FURRING HAT CHANNEL, 1/2" @ 32" O.C. HARD FASTEN J TRACK COMPONENT METAL SIDING- VERTICAL RIB, SEE ELEVATIONS EXT WALL ASSEMBLY, SEE A152 CONTI. HORIZONTAL 2 1/2" ZEE 16 GA. 4" ALIGN FLASHING TO WINDOW JAMB, WHERE OCCURS.
