The shaped acoustical panel mounts to a continuous wall assembly sized per plan using interlocking Z-clips secured with number 10 sheet metal screws spaced at 24 inches on center. Metal backing is provided at fastener locations as detailed on sheet A-9.10. Panel finishes, dimensions, and locations are specified in the interior elevations and project specifications.
4' - 6" SHAPED ACOUSTICAL PANEL, SEE SPECS. RE: INTERIOR ELEVATIONS FOR LOCATIONS AND FINISH Z CLIPS Z CLIPS METAL BACKING, SEE WALL PER PLAN #10 SMS @ 24" O.C. METAL BACKING, SEE 02 A-9.10 02 A-9.10
