An evaporator unit is suspended below overhead structural framing provided by others. Threaded rods drop down from beam and strut clamps attached to the structural members. Horizontal Unistrut channels span between the threaded rods to support the evaporator unit. Double locking nuts secure the rods and channels at the support points. A three-quarter-inch conduit and temperature sensor are routed along the assembly.
2X2X3/16" ANGLE THREADED ROD EVAPORATOR DOUBLE LOCKING NUT STRUCTURE (BY OTHERS) BEAM / STRUT CLAMP(TYP) STRUCTURE (BY OTHERS) UNISTRUT 3/4" CONDUIT TEMPERATURE SENSOR CLAMP 2 EVAPORATOR SUPPORT DETAILS
