An acoustical partition meets either a rated or non-rated wall with a one-inch gap filled with continuous fire safing insulation. The joint is sealed with a typical fire-rated joint sealant per Underwriters Laboratories test reference WW-D-0067. The assembly maintains acoustic and fire separation performance at the intersection of intersecting metal stud partitions.
GAP 1" FILL VOID WITH CONTINUOUS FIRE SAFING FIRE-RATED JOINT SEALANT,TYP. PER UL TEST REF. WW-D-0067 FIRE OR NON-RATED WALL A. RATED WALL INTERSECTION B. NON-RATED WALL INTERSECTION 13C A743 A8.15 11 A8.15 24
