A clean air vehicle stall is laid out with a width of nine feet and a length of eighteen feet measured to the curb face. The stall boundaries are marked with painted lines featuring curved ends with radii of six inches and ten inches at the centerlines. Lettering with an eight-inch height is painted on the pavement surface using white paint. Two coats of paint are applied over non-sealed asphalt paving, while one coat is applied over slurry sealed asphalt.
