This elevation view details glazing unit GL-1 with a sill height of 103'-0" and a head height of 108'-11" relative to the top of slab elevation at 100'-0". Vertical dimensions establish the positioning of the window unit with overall dimensions of 5'-0" in height and width. Section and detail reference markers point to drawing sheet A8.40.
T.O. SLAB 100' - 0" HEAD - A 108' - 11" SILL - A 103' - 0" GL-1 GL-1 3' - 0" 2" 4' - 8" 2" 11" 5' - 0" 2" 4' - 8" 2" 5' - 0" 3 A8.40 6 A8.40 9 A8.40
