Architectural · A-VKDHB

Yard Drain Grate in Pavement

Materials

Elements

About this detail

A sixteen-inch round drain grate is detailed with a decorative circular pattern, four-inch grinding pads for leveling across six places, and a one-inch vertical dimension profile. The grate accommodates pedestrian loads only, featuring a one-half-inch maximum slot opening for Americans with Disabilities Act compliance and pedestrian safety. Material options include gray iron, one hundred percent recycled aluminum, or C854 yellow brass. Finishes range from unfinished to black dip, enamel paint, polyurethane paint, or powder coat with an optional zinc undercoat. The assembly uses frame model 9001FDR-16, provides a forty-square-inch clear opening, and weighs eighteen pounds in iron, six pounds in aluminum, or twenty-two pounds in brass.
