Plan detail of a curtain wall corner mullion assembly framing around a structural column. The assembly features an extruded aluminum corner mullion system with associated glazing pockets and thermal breaks. A structural steel column profile is shown centralized within the interior frame zone. Grid lines and alignment axes intersect through the center of the column and glazing lines.
