A metal pipe or conduit with a diameter of three inches or less passes through a gypsum board and metal stud partition. A one-quarter-inch annular space surrounds the pipe within the opening. Acoustic sealant is applied continuously around the partition penetration to maintain sound ratings.
ACOUSTIC SEALANT @ PARTITION 1/4" ANNULAR SPACE METAL PIPE / CONDUIT (3" DIA OR LESS) GYPSUM BOARD AND METAL STUD PARTITION PARTITION AS SCHEDULED
