An upper wall-hung cabinet attaches to metal stud framing with wood blocking. The cabinet features adjustable shelving spaced with vertical peg holes at one-foot and one-inch intervals. Hinges mount near the top and bottom with specific setbacks. A bottom overhang extends two inches below the cabinet box.
