An aluminum storefront sill is seated on a concrete slab supported by a wide-flange steel beam and metal deck. The glazing assembly accommodates one-inch clear insulated glass units. Exterior wall construction below includes insulation, framing, and sheathing.
08 8000 - 1" INSULATED GLAZING, CLEAR 08 4113 - ALUMINUM STOREFRONT SILL 1'-4" INTERIOR 2"
