Landscape · A-V8MFZ

Tree Protection Fence Ra

Elements

About this detail

The assembly consists of a yellow, ultraviolet-resistant, wire-backed silt fence installed at the tree drip line or edge of disturbance to define the tree protection zone. Posts are spaced at four feet on center minimum and embedded two feet into the subgrade below finish grade. Planting soil for gardens or lawn mix is placed in four to six inch lifts with scarified subgrade. Construction notes mandate saving designated plants, prohibiting material storage within boundaries, and maintaining fencing throughout the project duration.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
