Architectural · A-V79FZ

Atrium Stair - West Elevation

Scale: 1/4" = 1'-0"
Units: imperial
Sheet: A5.11
Discipline: Architectural

Elements

Floors / Slabs Stairs

Text on the drawing

3RD FL. 454' - 7 3/4" 4TH FL. 468' - 7 3/4" 2ND FL. 440' - 7 3/4" EW7 460B F4 F4 F4 A 100
