A-V6HG7 — Detail

Architectural · A-V6HG7

Detail

Scale: SCALE: 1 1/2" = 1'-0"
Units: imperial
Sheet: A-563
Discipline: Architectural

Materials

Cold-formed Steel Concrete Gypsum / Drywall Metal (misc.)Timber / Wood

Elements

Beams Decks Floors / Slabs Partitions Walls

Text on the drawing

MECH. UPPER 122'-0 1/2" 2 1/2" METAL STUD RUNNER TRACK 5/8" GYPSUM BOARD 6" METAL STUD 6" METAL STUD RUNNER TRACK STRUCTURAL BEAM, RE: STRUCTURAL DRAWINGS SUSPENDED CONCRETE DECK, RE: STRUCTURAL DRAWINGS

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
