Architectural · A-V5S69

Millwork Reception Counter at Metal Screen

Materials

Elements

Columns Floors / Slabs Millwork / Casework

About this detail

This millwork reception counter detail features a solid surface epoxy terrazzo countertop laid over a three-quarter-inch plywood sub-base. The countertop is supported by HSS 3x1-1/2x1/4 hollow structural steel framing integrated with steel studs and high-pressure laminate wood paneling. The base assembly includes a metal-clad floor base, a floor-mounted foot rail, and an adjacent metal screen supported by posts. A horizontally mounted power outlet is integrated into the millwork housing.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
