A-V3WF8 — Daylight Panel Head

Architectural · A-V3WF8

Daylight Panel Head

Scale: SCALE: 3" = 1'-0"
Units: imperial
Sheet: A507
Discipline: Architectural

Materials

Aluminum Metal (misc.)Steel

Elements

Beams Drainage Facades / Cladding Insulation Walls Waterproofing / Flashing

Text on the drawing

FORMED METAL TRIM INSULATED-CORE METAL WALL PANELS CONTINUOUS SEALANT EXTERIOR ALUMINUM PROFILE TRANSLUCENT DAYLIGHT PANELS 54'-3"W x 27'-0"H BASIS OF DESIGN: QUADWALL 2.75" BY CPI DAYLIGHTING W27 GIRT 1/4"Ø WEEPS AT 24" OC SET PROFILE IN SEALANT 3"
