An architectural corner junction features an FP-1 fin intersecting an exterior mullion with a center line offset. Louver FP-2 abuts the assembly with a 3-1/4 inch clearance and a 7-1/4 inch dimension to the face of glass line. The fin depth varies from a minimum of 3-3/8 inches to a maximum of 1 foot 0 inches, with material information referenced to A364-A373. A dimension point establishes the geometric setting relative to the exposed slab edge in the mechanical room.
8 1 . 8 7 ° 3 1 / 4 " EDGE OF SLAB EXPOSED IN MECHANICAL RM LOUVER FP-2 OF MULLION FP-1 FIN F O G 7 1 / 4 " 4 1 / 4 " DIM PT 1 / 4 " T Y P . 1 / 4 " R E : A 3 6 4 - A 3 7 3 F O R F I N I N F O R M A T I O N F I N D E P T H V A R I E S 3 3 / 8 " ( M I N ) - 1 ' - 0 " ( M A X ) 1 3 / 3 2 " 1 1 1 / 1 6 " 1 3 / 3 2 " 2 1 / 2 "
