A tapered insulation sump surrounds the primary roof drain, measuring four feet by four feet with a slope of one inch per twelve inches directed toward the drain. Surrounding roof areas transition smoothly into the sump using tapered insulation.
4' - 0" 4' - 0" 4' - 0" TAPERED INSULATION SUMP AT PRIMARY DRAIN SLOPE 1" PER 12" TOWARD DRAIN PRIMARY DRAIN SEE MECHANICAL SLOPE SLOPE
