Architectural · A-V28SK

Stair Ceiling Step

Scale: SCALE: 1 1/2" = 1'-0"
Units: imperial
Sheet: A-562
Discipline: Architectural

Materials

Metal (misc.)Steel

Elements

Ceilings Doors Stairs

Text on the drawing

6 1/8" METAL PAN STAIR DOOR FRAME SCHEDULED CEILING FRAMED CEILING . SLOPE TO MATCH STAIR
