A metal parapet coping caps a treated 2x wood nailer atop a masonry wall, featuring a wood fiber tapered edge strip that slopes one-quarter inch per one foot. A waterproofing membrane extends below the nailer and is secured by a continuous metal cleat. Gasketed fasteners attach the coping assembly at spacings per specifications. One-quarter inch by four-inch masonry screw anchors secure the framing at twelve inches on center staggered.
TREATED 2x WOOD NAILER WOOD FIBER TAPERED EDGE STRIP EXTEND MEMBRANE BELOW NAILER AND SECURE METAL PARAPET COPING CONTINUOUS METAL CLEAT GASKETED FASTENERS SEE SPECIFICATIONS FOR SPACING 1/4"x4" MASONRY SCREW ANCHOR AT 12" OC STAGGERED WATERPROOFING MEMBRANE SLOPE 1/4" PER 1'-0" 6" 4" SEE ARCHITECTURAL FOR WALL TYPE
