A metal pan stair terminates at a concrete floor slab with an angle clip and slab anchorage designed by the stair manufacturer. The stair stringer supports metal treads with tread depth equal to the stair depth, while metal grating treads occur at similar conditions per detail. A wall-mounted handrail is provided alongside the stair run.
CONC FLOOR SLAB AS OCCURS STRINGER BY STAIR MANUF WALL MOUNTED HANDRAIL, SEE STAIR TREAD PER DETAIL MTL GRATING TREAD AT SIM CONDITION PER DETAIL 3' - 0" ANGLE CLIP & SLAB ANCHORAGE PER STAIR MANUF TREAD DEPTH EQ TO STAIR DEPTH TREAD
