A painted steel channel stringer supports concrete-filled metal pan treads rising from the finish floor elevation at the bottom landing. A one-and-one-half-inch diameter standard steel pipe guardrail and a one-and-one-quarter-inch diameter standard steel pipe handrail are mounted on one-and-one-half-inch diameter standard steel pipe posts spaced at four feet on center maximum. All posts and rail components are welded to the stringer. All connections are welded and ground smooth.
3'-6" MIN. TYP. 3'-0" TYP. TREAD + 1'-0" 6 - FINISH FLOOR ELEV. STEEL CHANNEL STRINGER, PAINTED 1 1/2" DIA. STANDARD STEEL PIPE POST AT 4'-0" O.C. MAX. WELD TO STRINGER 1 1/2" DIA. STANDARD STEEL PIPE GUARDRAIL, PAINTED CONCRETE FILLED METAL PAN TREAD 1 1/4" DIA. STANDARD STEEL PIPE HANDRAIL, PAINTED NOTE: WELD ALL CONNECTIONS AND GRIND SMOOTH A728 2 MAX. 3 7/8"
